| Model Name | TITAN AX15 |
| System Type | Active 15" 2-way Bi-amplified |
| Frequency Response (+/-3dB) | 50Hz-20kHz |
| Frequency Range (-10dB) | 40Hz-20kHz |
| Calculated Max SPL @ 1m | 129dB |
| Transducers | |
| Low Frequency Transducer | |
| Size (mm / inches) | 381mm / 15" |
| Coil Size (mm / inches) | 75mm / 3.0" |
| High Frequency Transducer | |
| Type | Compression Driver |
| Coil size (mm / inches) | 44mm / 1.75" |
| Exit size (mm / inches) | 25mm / 1" |
| Diaphragm Material | Titanium |
| Nominal coverage (H * V) | Hybrid Symmetry Horn 100° * 80° |
| Electronics | |
| Amplifiers | |
| Power amp LF RMS/Peak Watts | 350 / 700w (Class D) |
| Power amp HF RMS/Peak Watts | 70 / 140w (Class D) |
| Controls - EQ | Note - EQ changed by DSP knob |
| DSP | Advanced user selectable presets. 1:FLAT 2:MONITOR 3:SPEECH 4:BASS 5:PUNCH 6:LIVE |
| Hi Pass switch | 90Hz |
| Amplifier Protection | Yes |
| Thermal Protection | Yes |
| Low line voltage shut down | 60% Nominal line voltage |
| Driver Protection | Independant LF and HF limiters |
| DC Protection | Yes |
| Short Protection | Yes |
| Clip Limiter | Turns on ~250w output |
| Limiter indicator | Red LED |
| Power indicator | Green LED |
| Connectors | |
| Inputs | |
| Input type | Switchable balanced mic or line level (Chan 1) |
| Input connector | 2 * XLR & 2 * 1/4" jack (Chan 1 Line/MIC) |
| Line output | |
| Line output connector | Switchable LOOP/MIX Balanced Female XLR |
| AC Power | |
| Power Supply | SMPS |
| AC Power Options | AC100-120V/220-240V~ 50/60Hz |
| Power on indicator | Rear LED |
| Hardware | |
| Rigging / Bracket / Mounting Options | 10 M8 threaded inserts including 4 M8 threaded inserts on bottom in OmniMount 30.0-type footprint |
| | 35mm receptacle with lock screw |
| | 2 carry handles (one on each side) |
| | Optional wall-mount bracket |
| LED Horn lighting (On/Off switch) | Yes |
| Enclosure | |
| Enclosure Material and finish | Injection Moulded Polypropylene |
| Colour options | Black / White |
| Grille Material & Finish | 1.2mm steel |
| Dimensions & Weight | |
| Dimensions - Unpacked | |
| Height | 728.5mm / 28.7" |
| Width Front | 480.6mm / 18.9" |
| Width Rear | 480.6mm / 18.9" |
| Depth | 395.6mm / 15.6" |
| Dimensions - Packed | |
| Height | 830mm / 32.7" |
| Width Front | 514mm / 20.2" |
| Width Rear | 514mm / 20.2" |
| Depth | 489mm / 19.3" |
| Net Weight (kg / lbs) | 22.94kg / 50.3lbs |
| Gross Weight (kg / lbs) | 27.7kg / 60.9lbs | 420 watts programme / 840 watts peak New IRIS X HF Drivers have been honed acoustically for high-frequency detail and power New 3" voice coil LF Drivers reject moisture for resistance in all environments New Proprietary 100° x 80° Hybrid Symmetry Horn design New category leading DSP functions 129dB Max SPL Available in black or white | New tweaked laminar rib structure Integral mixer functions Class D Bi-amplified Tough, yet lightweight Dynamic Polypropylene cabinet with rubber padded handles 10 x M8 rigging points and integral tripod stand adapter Rugged protective grille and top-stacking receptacles Trapezoid design for arrays as well as stage monitor applications Titan Tourbags available
|
|
