SPECIFIKACIJE:
System Type Passive Configuration 15" 2-way Frequency Response (+/-3dB) 50Hz-20kHz Frequency Range (- 10 dB) 40Hz-20kHz Sensitivity (2.83v/1m) 97dB Calculated Maximum SPL @1m 129dB System Rated Impedance 8? Low Frequency Transducer Size 381mm / 15" Voice-Coil Size 75mm / 3.0" Rated Impedance 8? LF Power (re:AES2-2012) 400W High Frequency Transducer HF Driver Type Compression Driver Voice-Coil Size 44mm / 1.75" Exit Size 25mm / 1" Diaphragm Material Titanium Rated Impedance 8? HF Power (re:AES2-2012) 40W Nominal Coverage (H x V) Hybrid Symmetry Horn 100°x80° Power System Continuous Power 400w System Programme Power 800W System Peak Power 1600w Crossover frequency 2.7kHz Input Connector 2 x NL4 (speakON compatible) Hardware 35mm Speaker Pole Insert with lock screw2 handles on sides
M8 x 10 rigging points Enclosure Enclosure Material Trapezoidal / Polypropylene Finish Black / white Grille Material & Finish 1.2 steel Dimensions - Unpacked Height 728.5mm / 28.7" Width Front 480.6mm / 18.9" Width Rear 480.6mm / 18.9" Depth 395.6mm / 15.6" Dimensions - Packed Height 830mm / 32.7" Width Front 514mm / 20.2" Width Rear 514mm / 20.2" Depth 489mm / 19.3" Weight Net Weight 22.0kg / 48.4lbs Gross Weight 26.8kg / 59.0lbs
400W RMS / 800W Program / 1600W Peak
129dB Max SPL
50Hz – 20kHz frequency response
Titanium HF Driver has been honed acoustically for high-frequency detail and power
15" LF Driver rejects moisture for resistance in all environments
Proprietary 100° x 80° Hybrid Symmetry Horn design
3" LF voice coil
Tough, yet lightweight Dynamic Polypropylene cabinet with rubber padded handles
10 x M8 rigging points and integral tripod stand adapter
Rugged protective grille and top-stacking receptacles
Trapezoid design for arrays as well as stage monitor applications
Available in black or white
Titan Tourbags available
