Zoom G6 - Guitar Multi Effects Pedal

MAXIMUM NUMBER OF SIMULTANEOUS EFFECTS9 effects
USER PATCHES240
SAMPLING FREQUENCY44.1 kHz
A/D CONVERSION24-bit 128x oversampling
D/A CONVERSION24-bit 128x oversampling
SIGNAL PROCESSING32-bit
FREQUENCY CHARACTERISTICS20 Hz - 20kHz (+0.5 db/-0.5 dB) (10?k load)
DISPLAY4.3" TFT color LCD (480x272)

INPUTStandard mono phone jack
Rated input level: -20 dBu
Input impedance (line): 500 ?k
RETURNStandard mono phone jack
Rated input level: -20 dBu
Input impedance (line): 1 ?M
AUX INStereo mini jack
Rated input level: -10 dBu
Input impedance (line): 10 ?k

OUTPUT RStandard mono phone jack
Maximum output level: +11.4 dBu (when output impedance 10 ?k or higher)
OUTPUT L/MONO (PHONES)Standard stereo phone jack
Maximum output level: +11.4 dBu (when output impedance 10 ?k or higher)
Headphones 24 mW + 24 mW (at 32 load)
SENDStandard stereo phone jack
Maximum output level: +11.4 dBu (when output impedance 10 ?k or higher)
INPUT S/N123 dB

L/R-99.3 dBu
SEND-99.0 dBu
CONTROL INPUTFP02M input
POWERAC adapter ( 9v DC 500mA, center negative) (Zoom AD-16)
USBPort: USB 2.0 Micro-B/Supported cable type: Micro-B
Guitar Lab: USB 1.1 Full Speed
Audio Interface: USB 2.0 Full Speed, 44.1 kHz/32-bit, 2 in, 2 out
- Use a USB cable that supports data transfer. USB bus power is not supported

STANDARDSCards that support SD/SDXC/SDHC specifications (class 10 or higher)
LOOPER44.1 kHz/ 16-bit stereo WAV
IR44.1 - 192kHz, 16/24/32-bit WAV
REMOTEZOOM BTA-1 or other dedicated wireless adapter
EXTERNAL DIMENSIONS228 mm (D) x 418 mm (W) x 65 mm (H)
WEIGHT1.94 kg
Note: 0 dBu = 0.775 V
