Wharfedale Pro DIAMOND STUDIO 5 - Studijski Monitor

140 watts
Continuous
DIAMOND STUDIO
HONEST AND UNCOLOURED
Honest, uncoloured sound
Balanced inputs – XLR, 6.3 mm combi jack
RCA stereo inputs
Class D Bi-amplified.
Woven fibreglass composite LF cones5.0” Active bi-amplified studio monitor
140 watts continuous
280 watts peak
110 dB Max SPL @ 1 M

SPECIFICATIONS

System TypeActive 5” 2-way Bi-Amplified
Freq. Range (-10 dB) Analog Input45 Hz-25 KHz
Maximum SPL (peak @1 m)110 dB
LF Transducer5” Fiberglass composite woofer
HF TransducerSilk Soft dome tweeter
Coil Size (mm / inches)25.4 mm / 1”
High Frequency Coverage (H x V)135° x 110°
Total Power Amplifiers140 W
Low-Frequency Power Amplifier (Class D)80 W Continuous / 160 W Peak
Crossover Frequency2.2 KHz
Equalization (dB)HF / LF Level Adjust (-2, 0, +1 ,+2)
System Volume-? to +10 dB
Amplifier ProtectionYes
Power On ProtectionPower switch on / off mute
Thermal ProtectionAmplifier shutdown, auto reset
Driver, DC and Short ProtectionYes
Limiter IndicatorRed LED
Power IndicatorGreen LED/white LED (LOGO)
Input typeBalanced / Unbalanced
Input ConnectorsTRS JACK / FEMALE XLR/RCA
AC Power Options100 V-240 V
Power On IndicatorLED
Cabinet MaterialMDF
Cabinet Colourblack
Height290 mm /11.42 in
Width180 mm /7.1 in
Depth240 mm /9.45 in
Height350 mm / 13.78 in
Width242.5 mm / 9.55 in
Depth303 mm / 11.93 in
Net Weight5.62 kg /12.4 lbs
Gross Weight6.47 kg / 14.2 lbs
