Specs :
Inputs: 1/4" TS Hi-Z Input (Front Panel)Balanced Mic Input via 500 Series Connector (Rear Panel) Output: Balanced Line Output via 500 Series Connector (Rear Panel) Maximum Input Level: Microphone Input: +1 dBu
DI Input: +18 dBu Input Impedance: Microphone Input: 6 Kilohms
DI Input (Balanced): 2.2 Megohms
DI Input (Unbalanced): 1.1 Megohms Pad: 13 dBu Gain Range: +16 to +67 dB Equivalent Input Noise: Microphone Input: -108 dBu
DI Input: -82 dB THD + N: Microphone Input:
0.0046% at +12 dBu Gain
0.0064% at +24 dBu Gain
0.012% at +32 dBu Gain
0.028% at +40 dBu Gain
0.085% at +50 dBu Gain
0.3% at +62 dBu Gain
DI Input:
0.007% at +12 dBu
0.11% at +40 dBu Bandwidth: 1 kHz, 600-Ohms Unbalanced Source, Unweighted: 10 Hz to 30 kHz Maximum Output Level: +28 dBu Output Impedance: 600 Ohms Phantom Power: 48 VDC Power Supply: ±15 V from 500 Series Rack Dimensions (W x H x D): 1.5 x 5.3 x 6.5" / 3.8 x 13.3 x 16.5 cm Weight: 0.8 lb / 0.4 kg Packaging Info Package Weight: 1.8 lb Box Dimensions (LxWxH): 13.1 x 10.6 x 4.5"
