SPL Volume 8 osmokanalni regulator glasnoće

Instrumentation amplifier, electronically balanced (differential), transformerless Nominal input level: +4dBu Input impedance: =22kOhm Output impedance: ‹600Ohm Max. input level: ›+20dBu Volume control range: -80dB bis -4dB Mjerenja

Frequency range: 10Hz-100kHz (100kHz = -3dB) CMRR: ›60dBu@1kHz THD & N (at +15dBu input level): ›-100dBu S/N (A-weighted): -102dBu Crosstalk L/R (at 1kHz): ›-80dBu Dynamic range: 120dB Napajanje

Toroidal transformer: 15VA Fuses: 250mA (230V), 500mA (115V) Voltage selector: 230V/50Hz; 115V/60Hz Power consumption: 15W Dimenzije i težina

(W x H x D): 215 x 80 x 220mm; 8.5" x 3.1" x 8.8" Depth incl. Potentiometer, Sockets: 245mm/9.8 inches Weight: 1.6kg/4.18lbs
