Microphone Preamp Type XLR Female (via Combo), Balanced Maximum Input Level +10 dBu (Balanced, min. gain) Gain Control Range 60 dB Frequency Response 20 Hz to 20 kHz (±0.15 dB, unity gain, 48 kHz)
20 Hz to 40 kHz (±0.22 dB, unity gain, 96 kHz) Dynamic Range > 110 dB (A-wtd, min. gain) Total Harmonic Distortion EIN Input Impedance 1.6 k? Phantom Power +48V, > 8 mA per input
Instrument Inputs Type 1” TS Female (via Combo), Unbalanced Maximum Input Level +15 dBu (Unbalanced, min. gain) Gain Control Range 60 dB Frequency Response 20 Hz to 20 kHz (±0.2 dB, unity gain, 48 kHz)
20 Hz to 40 kHz (±0.6 dB, unity gain, 96 kHz) Dynamic Range > 106 dB (A-wtd, min. gain) Total Harmonic Distortion Input Impedance > 1 M?
Line Inputs Type 1” TRS Female (via Combo), Balanced Maximum Input Level + 18 dBu (Balanced, min. gain) Frequency Response 20 Hz to 20 kHz (±0.05 dB, unity gain, 48 kHz)
20 Hz to 40 kHz (±0.10 dB, unity gain, 96 kHz) Dynamic Range > 118 dB (A-wtd, min. gain) Total Harmonic Distortion Input Impedance 10 k?
Main and Line Outputs Type 1” TRS Female, impedance balanced, DC Coupled Maximum Output Level +18 dBu (Balanced) Frequency Response 20 Hz to 20 kHz (±0.05 dB, unity gain, 48 kHz)
20 Hz to 40 kHz (±0.15 dB, unity gain, 96 kHz) Dynamic Range > 118 dB (A-wtd) Total Harmonic Distortion Output Impedance 51?
Headphone Outputs Type 1” TRS Female, Stereo, Unbalanced, x2 Maximum Output Level 175 mW/channel (56? load) Frequency Response 20 Hz to 20 kHz (±0.5 dB, 48 kHz) Dynamic Range > 110 dB (A-wtd) Total Harmonic Distortion Headphone Impedance (working range) 16? to 300?
Crosstalk Input to Input Output to Output Input to Output
Signal Level LEDs Clip -0.5 dBFS Signal 1 -2 dBFS Signal 2 -4 dBFS Signal 3 -6 dBFS Signal 4 -10 dBFS Signal 5 -20 dBFS Signal 6 -30 dBFS Signal 7 -50 dBFS
Digital Audio Connection Type Thunderbolt* ADC Dynamic Range 120 dB (A-wtd) DAC Dynamic Range 120 dB (A-wtd) Bit Depth 24 bits Internally Supported Sample Rates 44.1, 48, 88.2, 96, 176.4, 192 kHz
Clock Jitter Jitter Attenuation > 60 dB (1 ns in => 1 ps out)
Power 12 VDC, 5A, external power supply
Physical Dimensions Height 1.75" (44.45 mm) Depth 7" (177.8 mm) Width 19" (482.6 mm) Weight 6 lbs (2.72 kg)
