Mehanički Dimenzije 343,2 k 181,2 k 60,2 mm (13,5 k 7,1 k 2,4") Težina 819 g (1,8 lb) Materijal kućišta UV-stabilizovan polikarbonat Materijal montaže Legura aluminijuma, čelik Prečnik za montažu na stub 1~2,5" na spoljnom prečniku cevi Otpornost na vremenske uslove IPKS6 Hardver Mrežni interfejs (2) GbE RJ45 porta Interfejs za upravljanje Ethernet ViFi Način napajanja PoE Napajanje UniFi PoE prekidač 48V, 0,5A PoE adapter (uključen) Podržani opseg napona 42,5—57V DC Maks. potrošnja energije 9V Maks. TKS snaga 2,4 GHz 5 GHz 6 GHz 22 dBm 27 dBm MIMO 2,4 GHz 5 GHz 6 GHz 2 k 2 (DL/UL MU MIMO) 2 k 2 (DL/UL MU-MIMO) Maks. brzina prenosa podataka 2,4 GHz 5 GHz 6 GHz 573,5 Mbps (BV40) 2,4 Gbps (BV160) Pojačanje antene 2,4 GHz 5 GHz 6 GHz 8 dBi 8 dBi LED diode bele/plave Dugme Resetovanje na fabrička podešavanja Montažni zid, stub (uključeno) Radna temperatura okoline -30 do 60° C (-22 do 140° F) Radna vlažnost okoline 5 do 95% bez kondenzacije Sertifikati CE, FCC, IC softver ViFi standardi 802.11a/b/g/n/ac/ak (ViFi 6) Bežična bezbednost VPA-PSK, VPA-Enterprise (VPA/VPA2/VPA3) BSSID 8 po radiju VLAN 802.1K Napredno ograničenje KoS-a po korisniku Podržana izolacija saobraćaja gostiju Istovremeni klijenti 250+ Podržane brzine prenosa podataka 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6,5 Mbps do 300 Mbps (MCS0 - MCS15, HT 20/40) 802.11ac 6,5 Mbps do 1,7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) 802.11ak (ViFi 6) 7,3 Mbps do 2,4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) Zahtevi za prijavu UniFi Netvork verzija 8.1.127 i novije Interface Wi-Fi Local Area Network Architecture 10Base-T100Base-TX1000Base-T Number of Ports 2 Switching Protocol Ethernet Device Location External Wi-Fi Band Frequency 2.4 GHz5 GHz Status Indicator Activity Status Encryption Algorithm WPA-PSK WPA WPA2 WPA3 WPA3-Enterprise Networking Compliant Standards IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.1Q(VLAN) IEEE 802.11n IEEE 802.11ac IEEE 802.11ax Networking Features Power over Ethernet (PoE) MU-MIMO Certifications CE, FCC, IC LAN 2 (RJ-45) Power Consumption Operational 9 W External Color White Included Accessories Quick Start Guide Protection Standarts IPX6 Built-in Devices Reset Button Depth (mm) 181.2 mm Height (mm) 343.2 mm Width (mm) 60.2 mm Nominal Weight 0.819 kg Maximum Operating Ambient Temperature 60 °C Maximum Operating Humidity 95 % Minimum Operating Ambient Temperature -30 °C Minimum Operating Humidity 5 % Warranty Products Returnable Da Warranty Term (month) 12 month(s) Warranty Term Notes 24 months - for EU Warranty validation Criteria Serial Number Pack Weight Brutto (kg) 2.5086 kg Pack Weight Netto (kg) 1 kg Pieces in pack 1 Retail Packaging Net Weight Carton 0 kg Retail Packaging Net Weight Plastic 0 kg Packs in Box 3 Package Type Retail Interfejs Wi-Fi Standardi mrežne kompatibilnosti IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.1Q(VLAN) IEEE 802.11n IEEE 802.11ac IEEE 802.11ax Spoljašnja boja Bela Uključena dodatna oprema Brzi vodič za početak Ugrađeni uređaji Reset Button Dubina (mm) 181.2 mm Visina (mm) 343.2 mm Širina (mm) 60.2 mm Nominalna težina 0.819 kg Maks. radna temperatura okoline 60 °C Maks. radna vlažnost 95 % Min. radna temperatura okoline -30 °C Pack Length (mm) 395 mm Pack Width (mm) 245 mm Pack Height (mm) 105 mm Box Length (mm) 442 mm Box Width (mm) 289 mm Box Height (mm) 388 mm Box Weight Brutto (kg) 7.526 kg EAN Code 810084695180
