Switch Tenda TL-SG105 Gigabit 101001000Mbps

HARDWARE FUNCTIONSStandards and protocolsIEEE 802.3i / 802.3u / 802.3ab / 802.3x, IEEE 802.1pinterface5 10/100 / 1000Mbps, auto-negotiation, auto-MDI / MDIX portsNumber of fansFanlessExternal power supplyExternal Power Adapter (Output: 5VDC / 0.6A)LEDsSystem Power
Link / Act indicators per port built into each RJ-45 portDimensions (W * D * H)3.9 x 3.9 x 1.0 in. (100 x 98 x 25 mm)Maximum power consumption2.3W (220V / 50Hz)Max Heat Dissipation7.83 BTU / hourPERFORMANCEPacket forwarding rate7.4MppsMAC address table2KPacket cache1MbJumbo frames16KBSOFTWARE FUNCTIONSAdvanced featuresGreen Technology
802.3X Flow Control
802.1P / DSCP QoS (for V2 and later version)
IGMP SnoopingTransfer methodStore and ForwardOTHERSCertificationCE, FCC, RoHSPackage content5-Port 10/100 / 1000Mbps Desktop Switch
Power Adapter
Installation GuideSurroundingsOperating Temperature: 0 ° C ~ 40 ° C (32 ° F ~ 104 ° F)
Storage Temperature: -40 ° C ~ 70 ° C (-40 ° F ~ 158 ° F)
Operating Humidity: 10% ~ 90% non- condensing
Storage Humidity: 5% ~ 90% non-condensing
